FOTOBLECH - Metal design with patterned perforated metal sheets
A software converts any photos in perforated plates with different sized holes. Our patented algorithm ensures a high quality presentation.
Designers and architects can also use our software online and let their creativity run wild.
You have a specific project in mind? We will assist you with your project!
Inquire now here:
Get to know the possibilities of FOTOBLECH
ARCHITECTURE
ART
DEMO LICENCE PRIVATE
Examples of our perforated sheets
Our patented process
2013 received Lunova GmbH the patent.
FOTOBLECH Includes: Fine Checkered Pattern
Inside Out. Discover the versatility of Fotoblech!
Our powerful tool allows you to create not only square, round, and triangular perforations, but also diamond-shaped ones.
The result? A sophisticated design that enhances any balcony.
With Fotoblech, you can unleash your creativity and add perfect accents.
Let yourself be inspired!
Image: Checks generated by the "Gradient" tool, with squares offset by 45 degrees, as Corten steel perforated sheet.
Ulm, Wohnen am Weinberg
Railing and privacy screen
Square and triangular perforation with a downward vertical flow that is opaque.
FOTOBLECH Special: Sloping sheets at their best
Patterns in a new form. With Fotoblech, the rows and columns of the perforated sheets can be adapted to the outer shape - even if it is not rectangular.
No matter whether it is a generated pattern from one of our pattern generators or a converted image template.
The hole sizes adapt to this as well.
This makes it very easy to implement slopes in fences, sloping walls or perspective effects without the edges "fraying" or showing unwanted staircase effects.
Image,
For comparison: With and without form fitting,
Example of a angular lamp design (PDF)
Facade of the Dorotheum / Motel One in Graz
Pattern generator Hexagon
The hexagon pattern uses the natural 60 degree diagonals of a perforated sheet with staggered rows.
Different sized perforations combined with a variety of filters create delightful vibrant patterns.
Catalog page,
image,
image,
PDF catalog
Fotoblech-Frame: China 1
Give your patterns a frame. Here you can see an example with the frame "China 1" (20.555).
The frames can be combined with all patterns, are fully parameterized in the desired frame thickness and spacing, and are compatible with all photo sheet filters.
Wien, Charasgasse
FOTOBLECH - Ornaments
Wrought iron railings reinterpreted. A modern-surface design with reminiscence on Viennese building traditions.
New function: Selective probabilities
Dynamically controlled perforation probability
If needed, we can control the probability of punching a hole or not depending on the potential hole size.
Small holes tend not to be punched. Large holes are more likely.
This results in a reduction of the number of punched holes by approx. 50% with a high contrast of the image at the same time.
Privacy screen in the entrance area
As here, photo sheets can be used to set accents and make statements. Functional and aesthetic at the same time.
Picture 1, Picture 2, Implementation: Dermet SLT OÜ
Figures of the fire brigade (Kollerschlag, Austria)
Artist: Otto Saxinger
Owner: Freiwillige Feuerwehr Kollerschlag
Implementation: Brüder Resch Hoch- u. Tiefbau
Double-shell curved and interconnected elements create a lively motif that offers different impressions depending on the viewing direction. The contours of the free-standing figures were lasered. Figures at night
FOTOBLECH - Coarse perforation with fine transitions
Sharp transitions. The transitions between the hole sizes are calculated in such a way that they appear sharp and there are no steps in the slopes.
Project number: 210520-01
Our pattern generator pulls the stripes: stripes
Stripe pattern with tiles of random horizontal or vertical alignment in which individual areas visually merge into a conglomerate.
The tile sizes and their spacing are freely selectable.
Catalog page,
image,
image,
PDF catalog
FOTOBLECH-Balconies in Vienna Liesing, Eschenpark
Floral pattern. An abstract floral pattern cascades over all parts so that the pattern runs continuously.
Due to the pattern arrangement, different high railings form a uniform image.
Optimum transparency. By sampling on a scale of 1:1, the optimum transparency can be determined in advance.
This can be controlled almost arbitrarily and is usually between 20 and 25%.
Picture 3,
Picture 4,
Picture 5,
Picture 6
FOTOBLECH Special: Photo sheets with frame
Give your photo sheets a frame. A range of different frame shapes give visual support to the content.
The frame shape supports the desired expression, for example as a picture or fence panel.
The sheets themselves provide the frame for the sheets. The visually reduced evenness is maintained and not interrupted by uprights or substructures.
Example 1: Coten steel with "Gradient" pattern, jitter effect and frame "balcony01"
Example 2: Galvanised steel with floral pattern and "Balcony02" frame with vertical struts
FOTOBLECH-Railing in Vienna 22, Baranygasse
Generated pattern. A balcony railing from our "White Noise" pattern generator.
The square perforation runs in straight rows with only one hole size with a probability of 60%.
Made-to-measure unique items. All railing fields are calculated individually and the perforation fits exactly into the specified dimensions.
Although the fields are of different lengths in detail, the overall picture is homogeneous.
Motif collection: floral foliage
Floral motifs are very popular with us.
That is why we have put together 10 floral foliage motifs in a catalog.
With similar transparency and hole density, they are easy to compare.
All motifs on an area of 3 * 2m.
Motif PDF floral foliage (23MB)
Our catalogs: Generated patterns and FOTOBLECH references
Transparency as desired
The transparency of the sheets can be controlled as desired.
Balcony railings are very typical here: In the lower area it should usually be denser than above.
We can control the transparency of the surface, whether from a photo template or generated by our pattern generator, see photos.
Our software also calculates the free area for each photo sheet.
Facade of the town hall in Meschede
The facade was clad with Fotoblech, which show an abstract wave-shaped pattern with rough perforations.
With the kind permission of Henke AG. Catalog
It doesn't always have to be "just" a Fotoblech...
The results of our pattern generators can not only be used for photo sheets.
Numerous providers use the motifs for a wide variety of purposes:
Photo pillows, puzzles, towels, T-shirts and much more.
The output format PDF 1: 1 supports you optimally.
Here is the Pattern generator
Railing motif from the perforated sheet pattern generator
Freely selectable line spacing
Normally, the line spacing results automatically from the selected hole spacing.
Now the distances can be freely selected and great effects can be achieved, as can be seen here in examples in combination with the "Jitter" function.
Pictures:
Example 1,
Example 2
Pattern Hook: Creating hooks with FOTOBLECH
The pattern 'Hook' is characterized by geometric shapes at a 45-degree angle, formed by interconnected hook-like chains with irregular hole sizes.
The design can be either sculptural and space-defining or abstract, depending on the configuration.
Catalogue page,
Image,
Pattern Hook Filtered,
PDF-Catalog
fit2pattern: What doesn't fit - is made to fit ...
Usually, repeating patterns do not fit exactly on the given area.
With the fit2pattern function, however, we can adapt the patterns exactly in both directions.
The drawn areas and lines remain sharply outlined.
Images:
without fit2pattern,
with fit2pattern
Running Dog: A classic
Basic form of the classic meander, mostly from Friesian, from ancient Greece.
An orthogonal ornament that reminds of river loops.
Catalog page,
image,
image,
PDF catalog
Pattern raindrops
A vertically oriented stripe pattern that is reminiscent of raindrops.
With randomly long drip lengths and diameters
Of course, fully parameterized and combinable with all filters.
Catalog page,
image,
image,
PDF catalog
Square Kufi: Calligraphy as a pattern
Random patterns are generated based on one of the oldest calligraphic forms of Arabic script.
Distributed in a grid of any size, these "writing plates" create a harmonious surface.
Catalog page,
image,
image,
PDF catalog
Forest motif as a railing and box house cladding
Dancing holes: our filter "Jitter".
With our filter "Jitter" we let the holes dance around the original position. See here on the left without and with filter.
Up and down with our pattern generator: Up and Down
Randomly meshed pattern with rectangular areas that emerge from or press into the layer.
The picture shows the combination with the special filter "Jitter".
Usually the holes are lined up.
Not so with this filter ...
Catalog page,
image,
image,
PDF catalog
Pearl necklaces as a pattern: Strings
Beaded pattern in various lengths and sizes.
A horizontally aligned pattern, in which the web widths can be minimal,
because the pattern always alternates between two different hole sizes.
Catalog page,
image,
image,
PDF catalog
Blades of grass as a railing motif: Opaque in the right places
Pattern generator IKO - chain links
Pattern with a chain-like structure and random hole sizes.
A geometric pattern that takes special account of the transition from one tile to another.
Catalog page,
image,
image,
PDF catalog
FOTOBLECH as a railing and stairwell cladding
Pattern generator Comfort Line - meshed networks
Random columns and row hole sizes are combined and spun into a network.
Reminiscent of fabric with almost endless possibilities of variation and levels of abstraction.
Catalog page,
image,
image,
PDF catalog
FOTOBLECH with Domico system facade
ABC-Text pattern with hidden messages
The texture in the truest sense of the word: ABC pattern generator.
A random sequence of letters with hidden messages.
Fully parameterized and combinable with various filters.
Catalog page,
image,
image,
PDF catalog
Gradient pattern: Gradient hole sizes with decorative gaps
A very flexible basic texture generator.
Smooth hole sizes are combined with the same probabilities of punching.
Catalog page,
image,
image,
PDF catalog
White noise: the basic pattern with many possibilities
Like every pattern of our pattern generator, the basic form "White Noise" can be completely parameterized and thus achieve a wide variety of effects.
This includes, for example, the division into tiles, invert, filter ...
Catalog page,
image,
image,
PDF catalog
Creative design ideas with perforated plates
Perforated sheets offer many original, high quality decorative possibilities for the design of facades and privacy protection for indoor and outdoor use. With FOTOBLECH you give a building expression. Functions of the components are visible.
Here are some examples of the scope of FOTOBLECH
- Perforated sheets in facade design
An aluminum facade wins with a perforated metal punching on appeal. - Perforated sheets for the fence design
A fence made of perforated metal elements is not only weather resistant and provides the desired privacy,
but also has a highly decorative. - Perforated plates made of stainless steelas a screen:
Stainless steel blinds with metal stampings in decorative patterns or with stamped lettering can be customized and is a real eye-catcher.
References
in Gallneukirchen
(3mm anodized aluminum)
in Passau
(2mm Corten steel)
in Linz
(1,5mm RHEINZINK)
